PERFORMANCE DATA

Model MPD40 (Diesel) Data Head

Unit

Value

Concrete Output - rod side

cu.m/hr

40

Concrete Pressure - rod side (theoretical)

bar

80

TECHNICAL DATA

Model MPD40 (Diesel) Data Head

Unit

Value

Concrete Delivery Cylinder (diam x stroke)

mm

200 x 800

Hydraulic Cylinder (bore x rod x stroke)

mm

90 x 65 x 800

Strokes/min - rod side

count

23

Hopper Capacity

ltr

600

Engine Power

kW

60

Hydraulic System Pressure

bar

280

DIMENSIONAL DATA

Data Head

Unit

Value

Length

mm

5800

Width

mm

2100

Height

mm

3800 (3200)

Weight

kg

5800
